QUICK 2008D+ Hot Air Desoldering Station Intelligent 750W LCD Digital Display Welding Heat Gun For SMD PCB Repair Tool

Features:



Precise temperature control/auto sleep/intelligent working channel/intelligent digital display/automatic cold air design



Can be widely used in various chip-level repairs, PCB manufacturing, mobile phone motherboards, etc.



Support CH1/CH2/CH3 three-channel selection, click CH1/CH2/CH3 to select channel 1/channel 2/channel 3 respectively, long-press the channel button, you can store the current channel air volume and temperature value



Air gun sleep, cold air protection, longer heating core life, built-in brushless fan, soft rotating wind, uniform wind force, precise control



Magnetically controlled switch control, convenient real-time operation, put the handle on the handle rack and sleep immediately, with automatic sleep function, the parameters can be set in the sleep state



Short press the "+" or "-" button, the temperature will rise or drop by 1℃, long-press the "+" or "-" button, the temperature will rise or drop rapidly



Turn the knob clockwise to increase the air volume, and vice versa, to decrease the air volume. A large-range adjustment knob can quickly increase or decrease the air volume.



Digital LCD Real-time display of temperature and air volume, which can be adjusted freely, which is more convenient



The front panel of the host is equipped with a switch design, so there is no need to cut off the power frequently, and it is more convenient to cut off the power



Strip heat dissipation grid design, with significant heat dissipation effect and better performance




Specification:

Product Name: Hot Air Desoldering Station



Model: Quick 2008D+



Display Type: LCD



Power: 750W



Voltage: 110V/220V



Temperature: 100°℃-500℃



Air Volume Range: 1-100 Level



Air Volume: 30L/min(Max)



Product Size: 170*151*98mm



Package Size: 330*180*230mm



Net Weight: About 1.5kg



Gross Weight: About 1.9kg



Package includes:



1 x Main Unit



1 x Hot Air Gun Handle



1 x Air Gun Holder



3 x Air Nozzle



1 x Power Cord
